The Shelf starter doesn’t ship the verify_shelf_page tool. By the end of this walkthrough, you’ll have built it yourself and be able to build an equivalent tool for a different verification target in your own project.

Before you start, install the server dependencies:

npm install -D @modelcontextprotocol/sdk zod

1. The registration — .mcp.json

Open .mcp.json at the repository root and add the shelf-verification entry:

{
  "mcpServers": {
    "shelf-verification": {
      "type": "stdio",
      "command": "npx",
      "args": ["tsx", "./tools/shelf-verification-server/server.ts"],
      "env": { "SHELF_BASE_URL": "http://127.0.0.1:4173" }
    }
  }
}

Notice it runs under tsx (TypeScript directly, no build step) and passes the base URL via environment, not as a command-line argument. That matters because the same server file can point at a local preview, a staging URL, or a live dev server without a code change.

Question: why stdio instead of HTTP? (Answer: MCP’s stdio transport keeps the server scoped to one client and one conversation. No port management, no authentication, no exposed network surface. The MCP host spawns the server as a subprocess and talks to it over pipes — ideal for repo-local tools like this one.)

2. The server file — tools/shelf-verification-server/server.ts

Create tools/shelf-verification-server/server.ts. It’s a short file — walk the four sections:

Imports, constants, server instance

import fs from 'node:fs';
import path from 'node:path';
import { McpServer } from '@modelcontextprotocol/sdk/server/mcp.js';
import { StdioServerTransport } from '@modelcontextprotocol/sdk/server/stdio.js';
import { chromium } from 'playwright';
import { z } from 'zod';

const STORAGE_STATE_PATH = path.resolve('playwright/.authentication/user.json');
const baseUrl = process.env.SHELF_BASE_URL ?? 'http://127.0.0.1:4173';

const server = new McpServer({ name: 'shelf-verification', version: '0.1.0' });

Two things to notice. First, STORAGE_STATE_PATH points at the same file Playwright’s storage-state setup writes — so the MCP tool shares an authenticated browser session with the rest of the test suite. Second, the server name (shelf-verification) matches the .mcp.json key. That’s not enforced by the SDK, but keeping them aligned is the difference between a readable debugger and an indecipherable one.

The tool contract

server.registerTool(
  'verify_shelf_page',
  {
    description:
      'Open the Shelf app and verify the public /shelf/[username] route renders correctly. ...',
    inputSchema: {
      username: z.string().min(1).describe('The reader handle, e.g. "alice" for alice@example.com'),
    },
    outputSchema: {
      ok: z.boolean(),
      bookCount: z.number().int().nonnegative(),
      consoleErrors: z.array(z.string()),
      url: z.string(),
    },
  } /* handler below */,
);

This is the whole contract: one input (username), four outputs (ok, bookCount, consoleErrors, url). The .describe() on the input is load-bearing — the agent reads it and uses it to decide what to pass. Without the description, a model could guess username means the full email address and the tool would fail to find the reader.

Question: why return url as part of the output when the agent theoretically knows what URL it asked about? (Answer: the agent only knows the username it passed. The server is the one that constructs the real URL — base URL plus path plus encoding. Putting url in the structured output means the agent can quote the exact URL in its summary to the user, which is much more useful than “I called verify_shelf_page with username alice.“)

The handler

async ({ username }) => {
  const targetUrl = `${baseUrl}/shelf/${encodeURIComponent(username)}`;
  const browser = await chromium.launch();
  try {
    // Reuse the authenticated storage state when it exists — even though
    // the /shelf/[username] page is public, the Playwright session stays
    // consistent with the rest of the workshop tooling.
    const contextOptions = fs.existsSync(STORAGE_STATE_PATH)
      ? { storageState: STORAGE_STATE_PATH }
      : {};
    const context = await browser.newContext(contextOptions);
    const page = await context.newPage();

    const consoleErrors: string[] = [];
    page.on('console', (message) => {
      if (message.type() === 'error') consoleErrors.push(message.text());
    });

    await page.goto(targetUrl);
    await page.getByRole('heading', { level: 1 }).waitFor();

    const bookCount = await page.getByRole('article').count();
    const result = {
      ok: consoleErrors.length === 0 && bookCount >= 0,
      bookCount,
      consoleErrors,
      url: targetUrl,
    };

    return {
      content: [{ type: 'text', text: JSON.stringify(result, null, 2) }],
      structuredContent: result,
    };
  } finally {
    await browser.close();
  }
};

The finally block is the most important line in the file. Without it, any throw above — a navigation timeout, a network error, a broken locator — leaks a Chromium process. The server stays up, the agent keeps calling the tool, and each failed call eats another 200 MB of RAM. finally is not optional.

The ok predicate is deliberately loose (bookCount >= 0) because the public /shelf/[username] route is a real page even for an empty shelf — “no books yet” is a valid render. If your domain says otherwise, tighten to bookCount > 0.

The return shape uses both content (for MCP hosts that read the text channel) and structuredContent (for hosts that honor the structured output schema). Returning both means the tool works against either kind of host without branching.

The transport

const transport = new StdioServerTransport();
await server.connect(transport);

Wire the server to stdio. server.connect() is the call that starts listening for JSON-RPC messages on the process’s stdin and replying on stdout. Nothing else.

Question: why isn’t this wrapped in a try/catch or a shutdown handler? (Answer: when the MCP host kills the subprocess, stdin closes and the transport unwinds cleanly on its own. Adding a SIGTERM handler to “close gracefully” is the kind of defensive code that sounds responsible but leaks complexity. If the subprocess dies hard, the host spawns a new one.)

3. Using it

Ask the agent to verify the shelf for alice. Example prompt:

Run verify_shelf_page for username “alice” and report the result. If ok is false, diagnose why.

The agent calls the tool, gets back the structured output, and acts on it.

Acceptance criteria

You can’t copy-paste your way through this one — the code is already there. You’re done when you can answer each of these without looking:

• Why does .mcp.json use stdio instead of HTTP transport?
• Why does STORAGE_STATE_PATH point at the same file Playwright uses?
• Why is the describe() on the username input load-bearing?
• Why does the output include url when the agent already passed the username?
• What happens if you remove the finally block and a page.goto throws?
• Why is the ok predicate bookCount >= 0 instead of bookCount > 0?
• Why does the return shape include both content and structuredContent?
• Why is there no explicit shutdown handler on the transport?

Plus one mechanical check:

• Restart your MCP host. Ask the agent to run verify_shelf_page for username alice. The result should include ok: true, a non-negative bookCount, an empty consoleErrors array, and the constructed url. Now add console.error('oops') to src/routes/shelf/[username]/+page.svelte, rerun the tool, and confirm ok flips to false and consoleErrors contains your string.

Stretch goals

• Add a second tool, check_accessibility, that runs axe-core against a URL and returns the violations as structured JSON. The axe-playwright-npm package makes this a ~15-line implementation.
• Add a third tool, database_snapshot, that calls the Shelf API to read the current state of the test database (books, shelves, users) and returns it as JSON. Useful for the agent to “look at” state without reading raw SQL.
• Make your server log all tool calls to a file at ./mcp-log.txt so you can tail the log while the agent works. Log to stderr, not stdout (stdout is the MCP protocol channel).
• Test your server standalone with the MCP Inspector before wiring it into the agent.

What you should be left with

A working custom MCP, registered with Claude Code, that the agent can call to verify Shelf’s primary page. A rule in CLAUDE.md that tells the agent to prefer it. A small but measurable reduction in the agent’s need to compose Playwright primitives from scratch.

This is the tightest verification loop we’re going to build today. The agent makes a change, calls verify_shelf_page, reads the result, and iterates. No human in the loop, no shell commands, no guessing. That’s the whole bet made real.
